DeFelsko PosiTector 6000 FRS Probe, Ferrous 90 Degree Cabled, 0-60 mils, for PosiTector Gauge Body
Details
The PosiTector 6000 FRS (PRBFRS) is a 90° regular cabled probe for measuring non-magnetic coatings (paint, powder coat, galvanizing) on steel and iron, sold without a gauge body. Plug it into an existing PosiTector Standard or Advanced body to add 0-60 mils (0-1500 µm) of coating thickness range without buying a second instrument. Typical use: right-angle probe for low-headroom areas such as inside pipe, channels and between flanges.
Features
- Magnetic principle measures non-magnetic coatings on steel and iron
- Right-angle head for measuring in tight, low-headroom spaces
- Constant-pressure stainless steel probe, hermetically sealed and waterproof
- Zirconia-toughened wear face and ruby tip hold calibration over long service
- Heavy-duty gold-plated locking connector built for industrial use
- Each probe keeps its own calibration data for true interchangeability
- Works with the PosiTector SmartLink for wireless use with a phone or tablet
Specifications
| Spec | Value |
|---|---|
| Probe model | FRS |
| Substrate | Ferrous (steel, iron) |
| Probe style | 90° (right-angle) regular cabled |
| Measuring range | 0-60 mils (0-1500 µm) |
| Accuracy | ± (0.05 mils + 1%) 0-2 mils; ± (0.1 mils + 1%) > 2 mils; ± (1 µm + 1%) 0-50 µm; ± (2 µm + 1%) > 50 µm |
| Probe operating temperature | Up to 50°C (120°F); higher surface temperatures possible with brief contact |
| Accuracy note | Fixed value plus a percentage of the actual reading |
| Warranty | Two years |
Conforms To
- ISO 2178, ISO 2360 and ISO 2808
- ISO 19840
- ASTM B244, B499, D1186, D1400, D7091, E376 and G12
- BS 3900-C5
- SSPC-PA 2
- US Navy NAVSEA PPI 63101-000 and NAVSEA 009-32
- AS 2331.1.4 and AS 3894.3-B
What's Included
- PosiTector 6000 FRS probe
- Long Form Certificate of Calibration traceable to NIST or PTB
- Two-year probe warranty
Gauge body sold separately.
Compatibility
- Connects to any PosiTector Standard or Advanced gage body; each probe stores its own calibration, so probes can be swapped freely
- Also works with the PosiTector SmartLink and the PosiTector App on iOS or Android
- Older gage bodies: check the serial number against DeFelsko's probe compatibility chart; a free gage update may be required
